Description:

A pulse oximeter is a medical device that indirectly measures the oxygen saturation of a patients blood (as opposed to measuring oxygen saturation directly through a blood sample) and changes in blood volume in the skin,producing a photoplethysmograph. It is often attached to a medical monitor so staff can see a patients oxygenation at all times. Portable battery-operated pulse oximeters are also available for home blood oxygen monitoring.

Features:

SPO2 and PR display, PR waveform and bargraph display
Battery voltage indicator
Friendly operation menu for the function setting
Dual dirsction display
Three levels adjustable brightness
Pulse sound function
Store and alarm function; can set upper and lower limits.
USBinterface to Computer, software can analyse, store and print the data.
Rechargeablr Li battery
Function switch used to activate measurement and turn off power; function key for menu setting
Low power consumption
Small volume(87(L) × 45(W) ×22(H) mm)lightconvenient to carry

Technical Parameters：

1.8' 65K Color TFT display, resolution 160*128
SPO2: 3599 Pulse Ratio30250BPM
Resolution: 1% for SPO2, 1BPM for pulse ratio
Accuracy: ±2% (7099), unspecified (<70%) for SPO2, ±2BPM or±2% (select larger) for pulse ratio
Power: 1 rechargeable Li battery
Charge manner : AC transformer or PC USB port
Can work more than 24 hours continuously
Interference resistance capacity against ambient light and measurement performance at low perfusion In the box

Inside The Box:

1. main unit
2. adult probe 1 pcs(Optional:infant probe or vet probe)
3. USB cable
4. software
5. adapter
6. User maunal


Software demo Screenshots



Warranty: One Year! Service: Whole Life!
